Sargent V33-10XG37-VSLL-LAKD Classroom Function Cylindrical Lock, Visual Indicator Trim Both Side, Green/Red, LA Keyway Keyed Random

  • SKU: V3310XG37VSLLUS26DLAKD
Dhs. 2,391.00/ea
Available (2 Weeks)
2 Weeks Lead Time
Finish: US26D-626 Satin Chrome

Buy Complete Door Hardware Set

? What's this?
Door hardware to Complete Your Set
Sargent V33-10XG37-VSLL-LAKD Classroo...
Quantity
–
+
From Dhs. 2,391.00
Sargent 351-UO-TB Powerglide Surface ...
Quantity
–
+
From Dhs. 1,434.00
Total

Sargent V33-10XG37-VSLL Classroom Function Cylindrical Lock, "VSL" Rose, "L" Lever Design, Visual Indicator Trim Both Side, Green/Red, 2 3/4 Backset, 4 7/8 Strike, LA Keyway Keyed Random [2] Keys, Grade 1

The Sargent V33-10XG37-VSLL is a Grade 1 cylindrical lock designed for classroom use, featuring a "VSL" rose and "L" lever design. It includes a visual indicator trim on both sides in green/red, a 2 3/4" backset, and a 4 7/8" strike plate. The lock comes with a LA keyway, keyed randomly, and includes two keys.

Classroom Function:

  • Deadlocking latch
  • Latch by either lever unless outside lever is locked by key
  • Key in outside lever locks or unlocks outside lever and retracts latch
  • Inside lever aleays operative
  • ANSI/BHMA F84

Double Indicator:

Option Code Outside Inside  Color
V33 Indicator Trim Indicator Trim  Green/Red - Icon
V66 Indicator Trim Indicator Trim  White/Red - Icon
V77 Indicator Trim  Indicator Trim Green/Red - Icon
V88 Indicator Trim  Indicator Trim White/Red - Icon
Manufacturer Sargent
SKU V33-10XG37-LAKD VSLL
Grade Grade 1
Installation Commercial
Origin United States
Unit of Measure Each
Base Material Brass, Bronze
UL Listing Type ANSI A156.2 (2017), A156.41, Series 4000, Grade 1, UL Listed
Limited Warranty 10 Year Limited Warranty
Fire Rated 3 Hours {A}
Burglar Rated No
Application Indicator with Icons
Function 37-Classroom
Lever/Knob Design L Lever
Rose/Escutcheon Design VSL Rose
Cylinder Type LA Keyway Keyed Random [2] Keys
Handing Non-handed
Door Thickness 1-3/4" to 2"
Bore Hole Diameter 2-1/8"
Std. Strike Width 1-1/4"
Screws Wood/Machine Screws
Product Type Cylindrical Lock

    Product Cut Sheet
