Sargent 55-56-8813J Rim Exit Device, Electric Latch Retraction, Request To Exit, Classroom Function, 37"-42" Door Width, Exit Only

  • SKU: 55568813JUS32D

Sargent 55-56-8813J Rim Exit Device, Electric Latch Retraction, Request To Exit, Classroom Function, 37"-42" Door Width, Exit Only

  • SKU: 55568813JUS32D
Sale priceDhs. 7,426.00/ea
Available (2 Weeks)
2 Weeks Lead Time
Finish: US32D-630 Satin Stainless Steel

Buy Complete Door Hardware Set

? What's this?
Door hardware to Complete Your Set
Sargent 55-56-8813J Rim Exit Device, ...
Quantity
+
Sale priceFrom Dhs. 7,426.00
Sargent LC-713-8-ETL Exit Device Trim...
Quantity
+
Sale priceDhs. 1,737.00
Sargent Rim Cylinders - Multiple Keyw...
Quantity
+
Sale priceFrom Dhs. 417.00
Total

Sargent 55-56-8813J Rim Exit Device, Electric Latch Retraction, Request To Exit, Classroom Function, 37"-42" Door Width, Hex Key Dogging, Grade 1, Reversible, Trim Sold Separately

The Sargent 55-56-8813J Rim Exit Device offers electric latch retraction and a request-to-exit feature tailored for classroom settings. Designed for door widths between 37" and 42", this Grade 1, reversible device operates with Hex Key Dogging and requires separate purchase of trim.

55- Request-to-Exit Option
SARGENT Request-to-Exit Signal Switch option for exit devices provides push rail monitoring for a variety of applications; such as to sound an alarm, initialize a delayed egress system, or de-energize an electromagnetic lock.

56- Electric Latch Retraction Option
SARGENT’s Electric Latch Retraction exit device is the perfect choice for high-traffic egress doors that require access control. This non-handed exit device rail is durable and easy to install. It utilizes a latch retraction motor rather than a solenoid, ensuring quiet operation ideal for locations such as conference rooms, theaters, and libraries. Once retracted, the door functions in a push/pull manner.

8800 Series Rim Exit Devices

The 8800 Series is tailored for standard width stile applications on both wood and metal doors. This reversible rim exit device is renowned for setting industry benchmarks in durability and reliability. It forms an integral part of Sargent’s comprehensive range of exit devices, offering robust performance and trusted security solutions.

  • Single point rim latching device
  • Single door & double door applications with mullions
  • Quiet operation and solid security
  • Devices are ANSI A156.3 - Grade 1
  • UL Fire and Panic listed

Manufacturer Sargent
SKU 55-56-8813J
Grade Grade 1
Installation Commercial
Origin USA
Unit of Measure Each
UL Listing Type UL10C & UL305
ANSI Number ANSI/BHMA A156.3
Restrictions None
BAA Qualified Yes
Limited Warranty 5 Years
Fire Rated No
Burglar Rated No
ADA Compliance No


Physical Appearance Wide Stile Pushpad
Device Type Rim
Mechanical Function Classroom
Device Length 42"
Electric Options Electric Latch Retraction
Hand Non-Handed
Dogging Options Hex Key Dogging
Includes Trim No
Minimum Stile Size 4 3/4"
Door Material Metal or Wood
Door Width 37" to 42"
Door Thickness 1 3/4" - 2 1/4"
Fire Rated No
Reversible Yes
Product Type Rim Exit Devices

Panic Handing Chart
