How Do Sargent 8800 Series Rim Exit Devices Work?

Sargent exit devices are designed to comply with ANSI/BHMA A156.3 Grade 1 standards and feature a single-point rim latch.

These exit devices are UL10C (Fire), and UL305 (Panic) listed devices and are installed on the surface of the door (rim installation). They’re activated by pushing a bar on the inside during emergencies for safe egress. These are also available as HC8800 or WS8800 for hurricane-resistant applications.

Find the Top Available Sargent Levers/Trims

The 8800 Series offers a variety of lever designs to suit your chosen exit device design and functionality:

  • B Curved No Return: A simple, easy-to-use lever design with a curved handle.
  • J Tubular Return: A lever with a tubular design that returns to a horizontal position after use.
  • L Contour Angles Return: A lever with a contoured angled design that returns to a horizontal position after use.
  • P Curved Return: A lever with a curved handle that returns to a horizontal position after use.

Rails and Options

The Sargent 8800 Series Rim Exit Devices are available in 4 different sizes to go with different door widths. Users can choose the rail size based on their door width.

  • E Rail is perfect for door widths ranging from 24” to 32” (no cutting required for 32” doors).
  • F Rail is ideal for door widths ranging from 33” to 36” (no cutting required for 36” doors).
  • J Rail is suitable for door widths ranging from 37” to 42” (no cutting required for 42” doors).
  • G Rail works for door widths ranging from 43” to 48” (no cutting required for 48” doors).

There are some additional options available, such as:

  • Factory Cut Rails: Quality Door offers pre-cut rails to match your exact door width, facilitating seamless installation.
  • Hex Key Dogging (Standard): Non-fire-rated devices come standard with hex key dogging. For cylinder dogging, specify 16-(#41 cylinder included). The less dogging option entirely removes the dogging function.
  • 700 Series ET Trim: The 8800 electrified exit device requires 700 Series ET Trim for proper functionality.
  • 8888 Multi-Function Exit Device: This unique device allows the trim to determine its function.

Discover the Best Selling Sargent 8800 Series at Quality Door

Quality Door offers a wide choice of Sargent exit devices with 700 series trims, keypads, and other options catering to diverse commercial applications. Whether you require keypad entry systems for better access control, wide stile push pads for wider doorways, or hurricane-resistant solutions for coastal locations, we have the right solution for you.

Explore the Sargent 8800 Series Catalog now available with options for electrification and a range of finishes, including Bronze US10B-613, BSP Black Suede Powder Coat, Polish Brass US3-605, 32D Stainless Steel and many more.
