Features

• Designed for use with self-closing fire and smoke barrier doors
• Use independently or with any fire or smoke detector system
• When de-activated, helps control the spread of fire and smoke by automatically releasing doors from an open position for simultaneous closing
• Fail-safe device: When electrical power fails, doors will release to close automatically
• Conforms to devices outlined in National Fire Protection Agency Standards Nos. 80 and 101
• Designed to work with SARGENT door closers
• Recommended vertical location is on the top rail of the door within 6" of lock stile edge
• When applications will not allow wall or floor magnets, consult the SARGENT FireGuard catalog for our line of Electronic Closer Holders
• Fits standard outlet box
• Holding force 35 lbs typical
• Voltage and Current: 120 VAC, 60 Hz., .020 amp 24 VAC/DC, 60 Hz., .020 amp 12 VDC, .040 amp
• EN Sprayed Aluminum Finish

Certifications
