Pemko DFM83SLI Full-Mortise Short Leaf Inset Continuous Geared Hinge in Dark Bronze Anodized Finish - 83"
Pemko DFM83SLI standard duty anodized aluminum Full Mortise shortleaf inset continuous geared hinges are designed mainly for new door applications. Also available in heavy-duty models
Pemko DFM83SLI Features
- Designed for use with doors that range between 1-3/4" to 2-1/4"
- Designed for use with hollow metal frames where the inset conforms to S.D.I. specifications for aligning doors and frames
- Fasteners are No. 12-24 x 7/16" FHUC, Type C, thread forming, no tapping required
Pemko DFM83SLI Specifications
| Finish: |
D - Dark Bronze Anodized |
| Length: |
83" |
| Width: |
25/32" (19.8 mm) |
| Height: |
2-3/8" (60.4 mm) |
| Manufacturer: |
Pemko |
Pemko DFM83SLI Certifications
| BHMA: |
BHMA Certified |
| UL: |
Fire Rated - UL10C - Positive Pressure |
| Other Certifications: |
PemkoHinge Fire Rating - UL76Y2 |
