Function

DA Vestibule

ANSI Function

F88

Lever/Knob Design

195SS Ligature Resistant

Lever/Knob Design Family

Anti-Ligature Lever

Rose/Escutcheon Design

3-13/16" Diameter

Cylinder Type

Key in Lever Cylinder

Num Pins

6

Std. Keyway

Schl C

Keying

Keyed Different

Key(s)

Cut

Num of Keys

2

Handing

Non-Handed

Door Thickness

1-5/8" to 1-7/8"

Std. Latch Number

1834A

Std. Latch Type

Dead Latch (Guarded)

Std. Latch Backset Dim

2-3/4"

Latch Bore Diameter

1"

Lock Face Size

2-1/4" x 1-1/8"

Bolt Projection

9/16"

Bore Hole Diameter

2-1/8"

Std. Strike Number

1135

Std. Strike Type

ANSI Strike

Std. Strike Height

4-7/8"

Std. Strike Width

1-1/4"

Screws

Combination

Product Type

Cylindrical Lock

Vendor

Napco Security Technologies

Manufacturer

Marks

SKU

195SSDA/32D

Grade

Grade 1

Installation

Commercial

Origin

USA

Unit of Measure

Each

UL Listing Type

UL 10C

ANSI Number

A156.2

Restrictions

None

BAA Qualified

Yes

Limited Warranty

Lifetime

Fire Rated

3 Hours {A}

Burglar Rated

No

ADA Compliance

No

Finish

630/US32D

Finish Description

Satin Stainless Steel

Finish Family

Matte Silver
