Cabinet:fabricated of 22 gauge stainless steel with exposed surfaces in architectural satin finish. All welded construction Door: fabricated of 18 gauge stainless steell with exposed surfaces in architectural satin finish. Secured with full-length piano hinge and two tumbler locks keyed like other Bradley accessory units Coin Box: fabricated of 22 gauge stainless steel. Secured with tumbler lock keyed differently than door for security
Installation:
Verify all rough-in dimensions prior to installation Recessed Unit: Requires rough wall opening 16 1/8"W x 27-7/8"H x 4"D. (fully recessed). Insert cabinet into wall opening and secure to framing (by installer) with included screws through holes provided. Shim at screw points as required Surface Unit:Secure cabinent to wall with screws (not included) at holes provided
Operation:
Insertion of coin permits clockwise rotation of handle (less than 90 °) to dispense product. Unit will not accept coin when product is empty. Access door allows refilling of product and emptying of coin box
Capacity:
18 napkins (3" x 4 1/4" x 1" box) and 28 tampons (5 1/8" long x 3/4" diameter tube). Dispenses most popular brands
