Converting a mechanical Sargent exit device into an electrified exit device can enormously enhance building security, access control, and code compliance, especially in high-traffic facilities. This upgrade allows doors to integrate with electronic access and fire alarm systems, providing both safety and convenience for environments like hospitals, schools, offices, and auditoriums.
Step-by-Step Guide: How to Convert a Mechanical Sargent Exit Device into an Electrified Exit Device
To electrify a Sargent 80 Series mechanical exit device, you’ll need an electric latch retraction kit, such as the Sargent M56-A Electric Latch Retraction kit or certified retrofit solutions from trusted suppliers. The process centers on replacing or upgrading the device’s mechanism to allow remote, powered latch retraction, enabling integration with access control systems like card readers or push buttons.
1. Choose the Correct Electrification Kit: The Sargent M56A Electric latch retraction kit is engineered specifically for 80 Series, 8888, 8804, and 8813 exit devices. Match the kit to your rail type (E, F, G, or J) and door width for proper fit.
2. Remove the Mechanical Device: Take the exit device off the door following Sargent’s installation instructions, ensuring all power to the opening is shut off for safety.
3. Install the Electrification Hardware: Position the electric latch retraction mechanism under the push bar per the kit’s templates. Secure all components and reconnect the push rail to the latch as directed.
4. Run Power and Connect: Wire the device to a 24V filtered, regulated DC power supply, following all local codes, and connect the new electrified function to your building’s access control or alarm system. Kits like the M56A often include an adjustable timer for retraction duration, supporting easy post-install tuning and setup for optimal performance.
5. Test and Configure: After assembly, restore power and test all functions, including electronic dogging and latch retraction. Adjust the retraction timing and switching modes (power mode or timer mode) as needed.
Refer to our Installation Video for more information
Popular Electrified Trims and Accessories
Sargent electrified trims are engineered to provide secure, keyless entry and seamless integration with access control systems for commercial exit devices. One of the most popular options is the ETL (Electrified Trim Lever), which offers electronic control of the outside lever. In fail secure mode, the lever is locked when there is no power, requiring a key for entry, while fail safe mode unlocks the lever upon power loss, ideal for facilities where building safety codes mandate free egress during emergencies.
Among the widely adopted trims, the Sargent 700 Electrified Trim is frequently paired with rim exit devices, enabling remote locking and unlocking from a central security system or reader, suitable for high-security environments and high-traffic doors. The ETL trim options are available in different voltage configurations, supporting both 12V and 24V continuous duty applications, and can be matched to various exit device models, including wide and narrow stile doors for maximum versatility.
For applications needing electronic keypad access, the Sargent KP80 Keypad Series brings added convenience, letting users enter via PIN codes without a key or card. This is ideal for areas requiring controlled yet user-friendly access, such as labs or restricted office spaces.
Each electrified trim, including specialized versions like night latch electrified trims and blank escutcheon lever trims, is designed to handle the demands of commercial settings while ensuring compliance with fire and life safety requirements, making them well-suited for schools, healthcare facilities, and government buildings. These trims combine robust mechanical construction with the flexibility of electronic access, providing both enhanced security and operational efficiency.
Applications: Mechanical vs. Electrified Sargent Exit Devices
-
Mechanical Exit Devices: Best suited for standard egress needs on perimeter or interior doors in schools, offices, retail stores, and public buildings where a simple push-bar emergency exit is sufficient.
-
Electrified Exit Devices: Essential for controlled entryways in hospitals, campuses, theaters, and government facilities. They provide for remote door unlocking, integration with fire alarm systems, and enhanced code compliance for life safety and ADA accessibility.
Choosing the Right Sargent Model for Your Facility
-
Schools and Universities: Sargent 80 Series exit devices with electrified kits support both secure lockdown and mass egress; electrified trims allow connection to central access management.
-
Healthcare Facilities: Electrified Sargent exit devices, especially with motor-driven latch retraction, enable remote nurse call access and comply with codes for secure, quiet operation on fire doors.
-
Commercial and Government Buildings: Sargent 8800 and 8888 series, when electrified, provide high-security access control and monitoring, meeting the demands of modern entryways.
-
Auditoriums, Theaters, and Stadiums: The ability to dog and undog exit devices electronically makes crowd management easier while maintaining compliance with life-safety requirements.
Why Electrify Sargent Exit Devices?
Upgrading to an electrified Sargent exit device elevates your system by enabling seamless access control connectivity, adding monitoring features, and flexible operation modes. These enhancements contribute to both operational efficiency and heightened security, critical priorities for any facility management team seeking long-term value and compliance with modern safety standards.
